59
8.Spezifikation / Specifications
Maße, Gewicht / Physical
Länge / Length...........................................................................................390mm (15,35in.)
Breite / Width.............................................................................................308mm (12,13in.)
Höhe / Height.............................................................................................536mm (25,10in.)
Gewicht / Weight.........................................................................................15,5kg (34,2lbs.)
Netzanschluß / power connection......................................................100-240VAC, 50-60Hz
Maximale Leistungsaufnahme / Total power consumption..........................................850VA
Durchschnittliche Leistungsaufnahme / average power consumption.........................400VA
Standby power consumption, all effects static, zero light............................................<40VA
Maximale Umgebungstemperatur / maximum ambient temperature................40°C (104°F)
Minimale Umgebungstemperatur / minimum ambient temperature......................5°C (41°F)
Lichtquelle / Light source................................................................61x RGBW Osram Ostar
Lichtstärke / total luminous power................................................17500 lumen (Zoom max.)
Pan........................................................................................................ .........................430°
Tilt........................................................................................................... ........................300°
Zoom.................................................................4°- 48° (4°- 33° 1/2 peak, 8°- 48° 1/10 peak)
Farbtemperatur / colour temperature.......................................CTC, variable 12500K-2500K
Farbe / Colour................................................................................................schwarz / black
Gehäuse / Housing....................................................................................................PC ABS
Schutzklasse / IP rating..................................................................................................IP 20
Aufstellungsort / Location..........................................................Innenraum / Indoor use only
Aufnahme / Mounting..............................................................................2x Omega brackets
Position / Orientation..............................................................................................jede / any
Mindestabstand zu brennbaren Gegenständen /
Min. distance to combustible materials.........................................................0,5m (39,37 in.)
Netzeingang / AC power input.............................Neutrik PowerCon NAC3MPA (blau / blue)
Netzdurchgang / AC power throughput..............Neutrik PowerCon NAC3MPB (grau / grey)
DMX in / out USITT DMX512.............................................................5-pin, 3-pin in/out XLR
Elektronik / Electrical
Temperatur / Thermal
Optik, Photometrische Daten / Optic, Photometric data
Effekte / Dynamic Effects
Konstruktion / Construction
Installation
Anschlüsse / Connections
