JB-Lighting A12 - Handbuch (Seite 41)

Standard 8 Bit
(S8) Standard 16 Bit
(S16) Compressed 8 Bit
(C8) Compressed 16 Bit
(C16)
Channel 1 Pan Pan Pan Pan
Channel 2 Pan fine Pan fine Pan fine Pan fine
Channel 3 Tilt Tilt Tilt Tilt
Channel 4 Tilt fine Tilt fine Tilt fine Tilt fine
Channel 5 Control Control Control Control
Channel 6 Shutter Shutter Shutter Shutter
Channel 7 Dimmer Dimmer Dimmer Dimmer
Channel 8 Zoom Zoom Zoom Zoom
Channel 9 Pattern Pattern Pattern Pattern
Channel 10 CTC CTC CTC CTC
Channel 11 Fixed Colors Fixed Colors Fixed Colors Fixed Colors
Channel 12 Pan/Tilt speed Pan/Tilt speed Red Red
Channel 13 Effect speed Effect speed Green Red fine
Channel 14 Blackout move Blackout move Blue Green
Channel 15 Red Red White Green fine
Channel 16 Green Red fine Blue
Channel 17 Blue Green Blue fine
Channel 18 White Green fine White
Channel 19 Blue White fine
Channel 20 Blue fine
Channel 21 White
Channel 22 White fine
5. DMX protocol
5.1 FIXTURE MODE „Standard“
The A12 offers 8 different channel options. With PERSONALITY -> FIXTURE MODE
(selection between Standard or Extended mode) and after with DMX MODE (selection of S8,
S16, C8, C16 and E8 respectively M1, M2, M3) you can select the different channel options.
The selected mode will be displayed in the main menu.
