Meinberg FDM509 - Handbuch (Seite 17)

17
Steckerbelegung
Z B D
2 VCC in (+5V) VCC in (+5V) VCC in (+5V)
4 /Reset A1 out GND
6 GND A2 out P_SEC in
8 Fail out RxD0 TxD0
10 Reserve in RxD1 TxD1
12 10MHz in GND Overflow out
14 SCL SCL_EN SDA
16 GND GND GND
20
22
24
26
28 L1
30 N
32 PE
