background image

Technical Data P8

Input impedance (XLR)

47 kOhm

Input sensitivity (XLR)

100mV

Signal-to-noise ratio (XLR) A-weighted

94 dB

Input impedance (Line)

47 kOhm

Input sensitivity (Line)

100mV

Signal-to-noise ratio (Line) A-weighted

94 dB

Input impedance Phono MM

47 kOhm

Input sensitivity Phono MM

2.6mV

Signal-to-noise ratio (Phono MM) A-weighted

90 dB

Input impedance Phono MC

40 / 120 / 600 Ohm

Input sensitivity Phono MC

0.26mV

Signal-to-noise ratio (Phono MC) A-weighted

74 dB

Voltage amplification (Line)

45 dB

Maximum input voltage (Line)

6V

Maximum voltage at XLR output

15V

Output impedance (XLR)

300 ohms

Maximum voltage at RCA output

8 V

Output impedance (RCA)

600 ohms

Volume adjustment range

99 dB

Control range for Balance, Bass, Levels

± 6 dB

Gain adjustment range

- 6 dB

Adjustment accuracy

0.1 dB

Channel balance

better than 0.05 dB

Frequency response

1Hz-110kHz (-3dB)

Harmonic distortion

< 0.03%

Stereo headphone output

6.3mm / 600 Ohm

12V Link Connection (short-circuit-proof)

3.5mm Mono minijack

SIS (Auto On/off)

after 15 minutes without a signal

Mains power connection

115V / 230V, switchable

Power consumption (in normal mode)

10 W

Power consumption (in standby mode)

< 0.5W

Analogue inputs

4 pairs of RCA, 2 pairs of XLR, 1 pair of

Phono

Digital inputs (24bit / 192KHz)

1 x Optical / 1x Co-axial

USB

1 x USB / Type B (48KHz)

Outputs

2 pairs of XLR, 1 pairs of RCA

Dimensions (W x H x D)

453 x 82 x 330 mm *

Weight

5,3kg

* Width including wooden sides, Height including feet, Depth with speaker terminals
