Technische Daten P8
Eingangsimpedanz (XLR) 47 kOhm
Eingangsempfindlichkeit (XLR) 100mV
Geräuschspannungsabstand (XLR) A-bewertet 94 dB
Eingangsimpedanz (Line) 47 kOhm
Eingangsempfindlichkeit (Line) 100mV
Geräuschspannungsabstand (Line) A-bewertet 94 dB
Eingangsimpedanz Phono MM 47 kOhm
Eingangsempfindlichkeit Phono MM 2,6mV
Geräuschspannungsabstand (Phono MM) A-bewertet 90 dB
Eingangsimpedanz Phono MC 40 / 120 / 600 Ohm
Eingangsempfindlichkeit Phono MC 0,26mV
Geräuschspannungsabstand (Phono MC) A-bewertet 74 dB
Spannungsverstärkung (Line) 45 dB
Maximale Eingangsspannung (Line) 6V
Max. Spannung am XLR-Ausgang 15V
Ausgangsimpedanz (XLR) 300 Ohm
Max. Spannung am RCA-Ausgang 8 V
Ausgangsimpedanz (RCA) 600 Ohm
Regelbereich Volume 99 dB
Regelbereich Balance, Bass, Höhen +/-6dB
Regelbereich Vorpegel -6dB
Regelgenauigkeit 0.1dB
Kanalgleichheit besser 0,05dB
Frequenzgang 1Hz-110kHz (-3dB)
Harmonische Verzerrungen <0.03%
Kopfhörerausgang Stereo 6,3mm / 600 Ohm
12V Link Anschluss (Kurzschlussfest) 3,5mm Mono Miniklinke
SIS (Auto On/off) nach 15 Min. ohne Signal
Netzanschluss 115V/230V umschaltbar
Leistungsaufnahme (Normalbetrieb) 10 W
Leistungsaufnahme (Standby) <0,5W
Analog Eingänge 4 Paar RCA, 2 Paar XLR, 1 Paar Phono
Digital Eingänge (24bit / 192KHz) 1 x Optisch / 1x Koaxial
USB 1 x USB / Typ B (48KHz)
Ausgänge 2 Paar XLR, 1 Paar RCA
Abmessungen (B x H x T) 453 x 82 x 330 mm*
Gewicht 5,31kg
* Breite mit Holzseitenteilen, Höhe mit Füssen, Tiefe mit Lautsprecherklemmen
First of all, we would like to thank you for choosing our AURUM M8 / P8 pre-ampli-
fier combination. We manufacture top-quality HiFi equipment which we hope will
delight you each time you use it. Our goal in all of this is to truly satisfy the require-
ments of music lovers just like you.
Even though you may already be knowledgable in using this type of equipment,
we’d still like to introduce some basic rules and guidance that will enable you to
get the best out of your purchase. Please do take a few moments to read this infor-
mation.
Safety instructions
Please read through these instructions carefully and follow all of the steps listed here
for installing the equipment. You must abide by all of the warnings and safety instruc-
tions that are stipulated on the unit and in this instruction manual. Keep this manual
close to hand so that you can consult it if you have any questions later on.
• The mains power cable and other connecting cables must be laid so that none
of them are crushed or damaged by furniture, are being trodden on, and / or
that nobody will trip over them.
• Take the power plug out of the socket during lightening storms or if the equip-
ment will not be used for a long time. Always pull the plug out of the socket and
never remove it by pulling on the cable!
• The amplifier‘s speaker terminals must only be connected up to the relevant
inputs on the speakers. You must never connect these terminals up to the electri-
cal mains supply (230V / 115V) as this will destroy the equipment and all inter-
connected units immediately. Therefore you must never fit plugs on these cable
connections to ensure that they can never be mixed up with mains plugs.
• Voltages above 30V can be present at the speaker terminals if high volume is
being used. Therefore you should never touch the terminals when the amplifier is
being used.
The lightening symbol inside an
equal-sided triangle is used to
warn you about the presence
of non-insulated components
carrying a dangerous, live
voltage that might cause severe
personal injuries. The exclamation mark inside an
equal-sided triangle indicates
that there is important information
available regarding the use and
maintenance of your equipment.
