4
Specifications
Video
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 4/8 inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs HDMI: 1 HDMI
VGA: 1
Video Resolution HDMI: 1920x1080, 1440x900, 1280x1024
VGA: 1920x1080, 1440x900, 1280x1024
Record Speed Real-time: 240ips (NTSC), 200ips (PAL) @ D1 (8-ch Model)
Real-time: 120ips (NTSC), 100ips (PAL) @ D1 (4-ch Model)
Playback Speed Full Duplex: 240ips (NTSC), 200ips (PAL) @ CIF (8-ch Model)
Full Duplex: 120ips (NTSC), 100ips (PAL) @ D1 (4-ch Model)
Inputs/Outputs
Alarm Input 4/8 terminal, programmable as NC or NO, 2.4V (NC) or 0.3V (NO) threshold,
5VDC
Alarm Output 1 relay output, terminal blocks, 1A@30VDC (NO)
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100Mbps, 1Gbps Ethernet (RJ-45)
Text Input POS Interface, ATM Interface
Connectors
Video Input Composite: 4/8 BNC
Monitor Output HDMI: 1 HDMI
VGA: 1 VGA
Alarm Input/Output Terminal Blocks
Ethernet Port RJ-45
RS232 Serial Port Two-connector terminal block
RS485 Serial Port Two-connector terminal block
IR Port 1 Remote Control
USB Port 2 (USB 2.0)
Storage
Primary Storage SATA hard disk drive
Secondary Storage USB hard disk drive or flash drive
General
Dimensions 10.4" (W) x 2.0" (H) x 7.5" (D) (265mm x 52mm x 191mm)
Unit Weight 3.3 lbs. (1.48kg)
Shipping Weight 6.0 lbs. (2.73kg)
Shipping Dimensions 14.0" (W) x 4.1" (H) x 13.4" (D) (355mm x 103mm x 340mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 12V , 2A (Adaptor: 100-240V~, 50/60Hz, 1.5A, 12V , 5A)
Power Consumption Max. 25W
Approvals FCC, CE
