19
Display Selecting displays the Display Menu.

Full Screen: Selecting and choosing the camera number button displays the selected
camera full screen.
 2x2, 1+5, 1+7, 3x3: Selecting , , or displays the cameras in the selected
multiview screen mode.
 Camera/Status OSD: Selecting Camera OSD or Status OSD toggles Camera
OSD or Status OSD On and Off.
Previous/Next
Group
Selecting or moves to the previous or next page.
Alarm Selecting resets the DVR’s outputs including the internal buzzer during an alarm.
Panic Selecting starts panic recording of all cameras, and selecting again stops panic
recording.
Camera Menu Selecting displays the Camera Menu.

Zoom: Selecting Zoom and choosing the camera number zooms the current playback
image of the selected camera on the screen.
 Show/Hide Text-In: Selecting Show Text-In or Hide Text-In shows or hides the
text-in data on the screen if the video was recorded with text-in data.
 Edit Group: Selecting Edit Group enters to the Active Cameo mode.
Export Selecting displays the Export menu.

A–B Clip-Copy: Selecting A–B Clip-Copy will set the starting point of the video to
be clip copied, and the icon displays at the bottom-left corner of the screen. Selecting
A–B Clip-Copy again will set the ending point of the video to be clip copied and
displays the Clip-Copy screen.
 Clip-Copy: Select Clip-Copy, and the Clip-Copy screen appears to allow clip copy
setup.
 Print: Selecting Print allows you to print a selected image.
Status Selecting will allow you to check the status of the DVR’s system, inputs and storage.
Data Source Selecting allows you to select the data source to be searched.
Exit Selecting exits the search mode and enters the live monitoring mode.
