Multi-Contact MA070 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
B...AX/...
S...AX/...
MA070 (de_en)
Montageanleitung MA070 (de_en)
Assembly instructions
Rundsteckverbinder mit AxiClamp-Anschluss
B8AX/25-35, B12AX/50-70,
B16AX/95-120, B20AX/150-185
S8AX/25-35, S12AX/50-70,
S16AX/95-120, S20AX/150-185 Round connectors with AxiClamp termination
B8AX/25-35, B12AX/50-70,
B16AX/95-120, B20AX/150-185
S8AX/25-35, S12AX/50-70,
S16AX/95-120, S20AX/150-185
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Vorbereitung der Leitung ...........................................................3
Leitungs-Anschluss mit AxiClamp.............................................3
Montage auf Fronttafel ..............................................................4 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Cable preparation ......................................................................3
Cable termination with AxiClamp ..............................................3
Assembly in panel .....................................................................4
Stecker
Plug
AxiClamp-Anschluss
AxiClamp termination Buchse
Socket
AxiClamp-Anschluss
AxiClamp termination
