Multi-Contact MA077 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 4
V1311
Tab. 1
B
A
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA077 (de_en)
Bedienungsanleitung MA077 (de_en)
Operating instructions
Crimpzange
V1311 Crimping pliers
V1311
Inhalt
Sicherheitshinweise....................................................................2
Crimpeinsätze montieren...........................................................3
Leitung vorbereiten ...................................................................3
Leitung vercrimpen ...................................................................3 Content
Safety Instructions ......................................................................2
Mounting the inserts .................................................................. 3
Cable preparation ......................................................................3
Cable crimping ..........................................................................3
1
2 3 4 5 6
Pos.
Bezeichnung
Description Leiterquerschnitt
Conductor cross section
mm²
1 V1311 -
2 13B25 150
3 13B27 185
4 13B30 240
5 13B32 300
6 13B38 400
