Multi-Contact MA259 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
PV-KST3-P AU PV-KBT3-P AU
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA259 (de_en)
Montageanleitung MA259 (de_en)
Assembly instructions
PV-Prüfstecker PV-KST3-P AU
PV-Prüfbuchse PV-KBT3-P AU PV test plug PV-KST3-P AU
PV test socket PV-KBT3-P AU
Inhalt
Sicherheitshinweise....................................................................2
Erforderliches Werkzeug ...........................................................3
Vorbereiten der Leitung .............................................................3
Crimpanschlüsse .......................................................................4
Crimpen .....................................................................................4
Montage ....................................................................................5
Leitungsführung ........................................................................6
Verbindung ................................................................................6 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Cable preparation ......................................................................3
Crimp connections ....................................................................4
Crimping ....................................................................................4
Assembly ...................................................................................5
Cable routing .............................................................................6
Engagement ..............................................................................6
Prüfstecker / Test plug Prüfbuchse / Test socket
