Definitions and Abbreviations of Values Used
Abbreviation
Display
(6 cha-
racters
maxi-
mum)
Description
In module
Meaning
Default value
Value range
Unit
Recipe datum
Process datum
Parameter datum
Calibration datum
Valve_kv_max kv_max
Conveying valve's maxi-
mum kv value
AUTO conveyance
STOP without empty run
STOP with empty run
For calculations of
Q or v
19
0.00-300.00
yes
Valve_lift_end Lift_end Final lift value of con-
veying valve at
Valve_kv_max
AUTO conveyance
STOP without empty run
STOP with empty run
For calculation of
Q or v
100 0-100
%
yes
Valve_char
V_char
Type of valve characteri-
stics (linear/percentually
equal)
AUTO conveyance
STOP without empty run
STOP with empty run
For calculation of
Q or v
0
0: linear
1: percentu-
ally equal
yes
t_rgl
t_rgl
Factor * 50 ms =
regulation's sample rate
AUTO conveyance
STOP without empty run
STOP with empty run
Regulation's sample
rate
1
0-255
yes
Q0
Q0
Air quantity, conveying
valve (operations)
AUTO conveyance
Determined and
calculated by con-
veying valve
(Q0=Qeff+QLP)
0
0-13000
m3/h
Q0N
Q0N
Air quantity, conveying
valve (standard)
AUTO conveyance
Determined and
calculated by con-
veying valve
(Q0=Qeff+QLP)
0
0-13000
Nm3/h
T1
T1
Actual temperature
AUTO conveyance
STOP without empty run
STOP with empty run
Measured value for
calculation of Q or v
0
2-160
°C
t14
t14
Pause: settling time
before conveying valve
CLOSES
STOP without empty run
After this period, the
conveying valve is
closed
60
none
s
t18
t18
Pause: settling time
before conveying valve
CLOSES
STOP with empty run
After this period, the
conveying valve is
closed
60
none
s
TB
Momentary absolute
temperature T2
AUTO conveyance
STOP without empty run
STOP with empty run
Measured value +
273K
0
0-160
°C
TN
Standard temperature,
0-point
AUTO conveyance
STOP without empty run
STOP with empty run
273K
273
°C
O
PERATION
Definition of the Display
a) Display of a value in the row of a table:
Maximum no. of characters per row: 16
Name
:
Value
Unit
6
1
5
4
1 6
7
8 12
13 16
Qeff
:
6000
m3/h
No. of places
Position
Example
