Kapitel: BIOS-Einstellungen Integrated Peripherals
Seite 48 Beckhoff New Automation Technology CB4051
5.6.1 OnChip IDE Devices
Phoenix – AwardBIOS CMOS Setup Utility
OnChip IDE Device
IDE HDD Block Mode [Enabled]
Item Help
IDE DMA transfer access [Enabled]
On-Chip Primary PCI IDE [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
*** On-Chip Serial ATA Setting ***
SATA Mode [IDE]
On-Chip Serial ATA [Disabled]
SATA PORT Speed Settings [Disabled]
PATA IDE Mode [Primary]
SATA Port P1,P3 is Secondary
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü IDE HDD Block Mode
Optionen: Enabled / Disabled
ü IDE DMA transfer access
Optionen: Enabled / Disabled
ü On-Chip Primary PCI IDE
Optionen: Enabled / Disabled
ü IDE Primary Master PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Primary Slave PIO
Optionen: Auto / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4
ü IDE Primary Master UDMA
Optionen: Disabled / Auto
ü IDE Primary Slave UDMA
Optionen: Disabled / Auto
ü SATA Mode
Optionen: IDE / RAID / AHCI
ü On-Chip Serial ATA
Optionen: Disabled / Auto / Combined Mode / Enhanced Mode / SATA Only
ü SATA PORT Speed Settings
Optionen: Disabled / Force GEN I / Force GEN II
ü PATA IDE Mode
Optionen: keine
ü SATA Port
Optionen: keine
