Technical Data
DVI-FiberLink · 20
Transmission module features
MULTIMODE TRANSMISSION MODULE
Data transmission
Type:
Fibre optics (2 fibres)
Port type:
LC duplex
Cable length (max.)
Multimode 50/125 μm,
class OM2:
550 metres (fibres with 500 MHz*km),
500 metres (fibres with 400 MHz*km)
Multimode 62,5/125 μm,
class OM1:
220 metres (fibres with 160 MHz*km),
275 metres (fibres with 200 MHz*km)
Power data
Wave length ():
850 nm (770 nm to 860 nm)
Optical power output (P
AVG
)
in 50 or 62,5 m MMF:
-9,5 dBm to -3 dBm
Receiver sensitivity (P
MIN
):
-17 dBm
Sensitivity – Stressed (P
S
):
-13,5 dBm (50 m MMF)
SINGLEMODE TRANSMISSION MODULE
Data transmission
Type:
Fibre optics (2 fibres)
Port type:
LC duplex
Cable length (max.)
Singlemode 9/125μm,
class OS1:
10 kilometres
Wave length ():
1310 nm (1270 nm to 1360 nm)
Leistungsdaten
Optical power output (P
AVG
)
in 9 μm SMF:
-9,5 dBm to -3 dBm
Receiver sensitivity (P
MIN
):
-19 dBm
Sensitivity – Stressed (P
S
):
-14,4 dBm
