Anhang
BK4000
25
Teil für bitorientierte Daten,
Digitale Ausgänge
relative
Byteadresse
Bitposition
Prozeßabbild in der
Steuerung
Position im Block
12
0
A12
POS07
12
1
A12
POS07
12
2
A12
POS08
12
3
A12
POS08
12
4
A12
POS09
12
5
A12
POS09
12
6
A12
POS18
12
7
A12
POS18
13
0
A13
POS19
13
1
A13
POS19
Teil für byteorientierte
Daten, Analoge Eingänge
relative
Byteadresse
Bitposition
Prozeßabbild in der
Steuerung
Position im Block
0, 1
keine
E0, E1
POS10
2, 3
keine
E2, E3
POS10
4, 5
keine
E2, E3
POS13
6, 7
keine
E2, E3
POS13
Teil für bitorientierte Daten,
Digitale Eingänge
relative
Byteadresse
Bitposition
Prozeßabbild in der
Steuerung
Position im Block
8
0
E8
POS01
8
1
E8
POS01
8
2
E8
POS02
8
3
E8
POS02
8
4
E8
POS03
8
5
E8
POS03
8
6
E8
POS04
8
7
E8
POS04
9
0
E9
POS05
9
1
E9
POS05
9
2
E9
POS06
9
3
E9
POS06
9
4
E9
POS15
9
5
E9
POS15
9
6
E9
POS16
9
7
E9
POS16
10
0
E10
POS17
10
1
E10
POS17
Die Positionen POS14 und POS21 sind in Bezug auf den Datenaustausch
nicht relevant. Sie erscheinen nicht in der Liste. Wird ein Byte nicht voll-
ständig genutzt, z.B.: E8, füllt er Buskoppler die restlichen Bits des Bytes
mit Nullen auf.
