Seite 22
BRONKHORST
®
Index Sub
Index
Beschreibung
DDE parameter
0x6415
0
CO Physical unit controller output
-
1
CO Physical unit controller output
-
0x6420
0
CO Setpoint switch W/W2
-
1
CO Setpoint switch W/W2
-
0x6421
0
CO Automatic / manual mode A/M
-
1
CO Automatic / manual mode A/M
-
0x6422
0
CO Controller on / off
-
1
CO Controller on / off
- (is described above)
0x6423
0
CO Controller mode
-
1
CO Controller mode
Control mode
0x6425
0
CO Control byte
-
1
CO Control byte
- (is described above)
0x6425
0
CO Status word
-
1
CO Status word
- (is described above)
0x7400
0
CO Effective current value Xeff (INT)
-
1
CO Effective current value Xeff (INT)
fMeasure
0x7401
0
CO Effective setpoint Weff (INT)
-
1
CO Effective setpoint Weff (INT)
fSetpoint
0x7402
0
CO Setpoint W (INT)
-
1
CO Setpoint W (INT)
fSetpoint
5
0x7403
0
CO 2
nd
Setpoint W2 (INT)
-
1
CO 2
nd
Setpoint W2 (INT)
-
0x7404
0
CO Lower setpoint limit W0 (INT)
-
1
CO Lower setpoint limit W0 (INT)
Capacity 0% (read only)
5
0x7405
0
CO Upper setpoint limit W100 (INT)
-
1
CO Upper setpoint limit W100 (INT)
Capacity (read only)
5
Der Wert von Object 0x6407:01 CO Decimal digits current value / set point wird automatisch ermittelt
und optimiert während der Instrument Power-Up.
5
Beispiel:
fMeasure = 1.15 ln/min
object 0x6407:01 CO Decimal digits current value / set point = 3
object 0x7401:01 CO Effective current value Xeff = 1.15 x (10 x 10 x 10) = 1150
object 0x6407:01 CO Decimal digits current value / set point = 4
object 0x7402:01 CO Setpoint W (INT) = 22500
fSetpoint = 22500 / (10 x 10 x 10 x 10) = 2.25 ln/min
3
Integer16 wird mit dem Wert des Objektes 0x6407:01 skaliert.
5
Integer16 wird mit dem Wert des Objektes 0x6407:01 skaliert.
