Text-based control of a matrix switch
IP-Control-API · 10
The reply of the matrix switch may look like the following example:
When using other parameters, replies look like this::
LIST OF INFORMATION ABOUT A MATRIX SWITCH
<?xml version="1.0" encoding="utf-8"?>
<root>
<result type="list">
<DviMatrixSwitch>
<item>
<id>0x00000028</id>
<!-- ID of matrix switch -->
<cl>DviMatrix</cl>
<!-- Device class of matrix switch -->
<type>DVICenter DP32</type>
<!-- Variant of matrix switch -->
<name>DVIC Virtlab</name>
<!-- Name of matrix switch -->
<poweredOn>true</poweredOn>
<!-- Status of power supply -->
<pushGet>yes</pushGet>
<!-- Enabled push/get function? -->
<tradeSwitching>yes</tradeSwitching> <!-- Enabled TradeSwitch function? -->
<ipSwitching>yes</ipSwitching>
<!-- Enabled IP-Control-API -->
</item>
</DviMatrixSwitch>
</result>
</root>
LIST OF INFORMATION ABOUT A USER MODULE
<?xml version="1.0" encoding="utf-8"?>
<root>
<result type="list">
<DviConsole>
<item>
<id>0x00000117</id>
<cl>DviConsole</cl>
<type>DVI-CON</type>
<name>CON 00000117</name>
<ownerId>189</ownerId>
<ownerCl>DviMatrix</ownerCl>
<ownerPort>0</ownerPort>
<enable>1</enable>
<poweredOn>false</poweredOn>
</item>
</DviConsole>
</result>
</root>
LIST OF INFORMATION ABOUT A TARGET MODULE
<?xml version="1.0" encoding="utf-8"?>
<root>
<result type="list">
<DviCpu>
<item>
<id>0x0000008A</id>
<cl>IoCpu</cl>
<type>DVI-CPU-UC</type>
<name>UC-Test</name>
<powered_on>false</powered_on>
</item>
</DviCpu>
</result>
</root>
