Multi-Contact MA081 Benutzerhandbuch
Seite 5
Advertising
![background image](/files/857783/content/doc005.png)
Advanced Contact Technology
www.multi-contact.com
5 / 8
±0,6°
±0
,2
mm
±0
,5
mm
±2°
±2°
±1
mm
±2°
±0
,2
mm
=
A
=
1)
1)
1)
=
P1/30...
P1/63...
P1/100...
P4/50... P4/63...
P1/30...
P1/63...
P4/50...
P4/63...
P1/100...
Maximale Montage Toleran-
zen
Maximum mounting offset
Montageanordnung für Be-
messungsspannungen von
500V und 600V
Mounting for rated voltage
500V and 600V
Typ
Type
≤ 500V
500V - 600V
Distanzkörper / Spacer
D-P4/50PC (15.5035)
mit Distanzkörper
with spacer
Befestigungsebene
Mounting surface
