Technical data
52 · G&D DL-Vision(M/S)
General module features
DL-VISION-CPU | COMPUTER MODULE
Interfaces
for console
Monitor:
per video channel
1 × DVI-D socket
Keyboard:
1 × PS/2 socket
1 × USB-A socket
Mouse:
1 × PS/2 socket
1 × USB-A socket
Interfaces
to computer
Video:
1 × DVI-D socket
PS/2 keyboard/mouse:
2 × PS/2 socket
USB keyboard/mouse:
1 × USB-B socket
Audio:
AR & ARU variants
1 × 3,5-mm jack plug (Line In)
1 × 3,5-mm jack plug (Line Out)
USB:
ARU & U variants
1 × USB-B socket
RS232:
AR & ARU variants
1 × D-Sub9 socket
Interfaces for
transmission
Video and input devices:
per video channel
1 × LWL LC duplex socket
USB (transparent):
ARU 2 variant
1 × LWL LC duplex socket
Other
interfaces
Network connection:
2 × RJ45 socket
DL-VISION-CON | USER MODULE
Interfaces
for console
Monitor:
per video channel
1 × DVI-D socket
Keyboard:
1 × PS/2 socket
1 × USB-A socket
Mouse:
1 × PS/2 socket
1 × USB-A socket
Audio:
AR & ARU2 variants
1 × 3,5-mm jack plug (Mirco In)
1 × 3,5-mm jack plug (Speaker)
USB:
ARU2 variant
4 × USB-A socket
RS232:
AR & ARU2 variants
1 × D-Sub9 socket
Interfaces for
transmission
Video and input devices::
per video channel
1 × LWL LC duplex socket
USB:
ARU2 variant
1 × LWL LC duplex socket
Other
interfaces
Network connection:
2 × RJ45 socket
