The DL-Vision(M/S) series
G&D DL-Vision(M/S) · 3
English
The DL-Vision(M/S) series
The KVM extenders of the DL-Vision(M/S) series consist of a computer module and a
user module.
The computer to be operated and an optional console are connected to the computer
module ( DL-Vision-CPU ). The remote console is connected to the user module
( DL-Vision-CON ).
Both computer module and user module are connected via two fibre optics. These
fibres transmit keyboard, mouse and digital video signals of the connected computer
and enable the user to operate the computer remotely.
The computer can be operated either at the remote console of the user module or at
the local console of the computer module.
Available device variants
The DL-Vision(M/S) series provides various devices that enable the transmission of
additional signals and the usage of several monitors:
NOTE: When applying a DL-Vision multi-channel and/or USB variant, any addi-
tional signals are transmitted via further fibre optics.
Model Video
channels
Keyboard
& Mouse
Audio &
RS232
USB 2.0
DL-Vision(M/S)-AR 1  
DL-Vision(M/S)-ARU2 1   
DL-Vision(M/S)-MC2-AR 2  
DL-Vision(M/S)-MC2-ARU2 2   
DL-Vision(M/S)-MC4-ARU2 4   
