Guntermann & Drunck DL-Vision(M/S) - Handbuch (Seite 121)

Technical data
G&D DL-Vision(M/S) · 55
English
DL-VISION(M/S)-MC4-ARU2-CPU | COMPUTER MODULE
Current consumption maximum: 100-240VAC/60-50Hz, 0.6-0.3A
Casing Material: anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D): 435 mm × 2 U × 284,5 mm
Weight: approx. 4,5 kg
Operating
environment
Temperature: +5 bis +45 °C
Air humidity: < 80%, non-condensing
DL-VISION(M/S)-MC4-ARU2-CON | USER MODULE
Current consumption maximum: 100-240VAC/60-50Hz, 0.7-0.4A
Casing Material: anodised aluminium;
nickel-plated steel (bottom)
Dimensions (W × H × D): 435 mm × 2 U × 284,5 mm
Weight: approx. 4,5 kg
Operating
environment
Temperature: +5 to +45 °C
Air humidity: < 80%, non-condensing
