Configuration
G&D DL-Vision(M/S) · 33
English
Selecting the EDID mode of the KVM extender
The EDID information (Extended Display Identification Data) of a monitor inform the
graphics card of a connected computer about different technical device features. The
information are usually transmitted via Enhanced-DDC (Enhanced Display Data Chan-
nel) from KVM extender to the computer without alteration.
A special EDID mode can be activated if the computer connected to the KVM
extender is assembled with a Barco PVS graphics card. This mode considers the spe-
cial treatment of EDID data by the graphics card.
Some resolutions can be selected using a special GUD profile. The profile names
refer to the resolution that is transmitted to the monitor when using this profile
Alternatively, the EDID profile of a monitor can be read in. The extender transmits
the profile to the connected computer. Detailed information about this topic is given
in the separate manual for the Config Panel web application.
How to select the EDID mode of the KVM extender:
NOTE: This function can only be (de)activated in the web application.
IMPORTANT: It might be possible that Barco PVS graphics cards do not create an
image in the Auto mode.
Config
Pan
el 1. Use the tree view to double-click on KVM Extenders > [All Extenders] .
2. Double-click the computer module of the KVM extender to be configured.
3. Click the General tab.
4. Use the EDID mode field to select between the following options:
[Auto]  automatic treatment of EDID data (default)
[BARCO PVS]  special mode for Barco PVS graphics cards
GUD DVI …  G&D profile for a particular resolution
Name  EDID profile read in by user
5. Click OK to save your settings.
NOTE: Please mind the activation sequence recommended on page 14 when initi-
ating or connecting another monitor.
