Driver Software for WINDOWS
101
IK220CntStatus
Supplies additional information on the last counter value of the
corresponding register.
Prototype: BOOL IK220CntStatus (USHORT Axis,
USHORT Latch, USHORT* pRefSta,
SHORT* pKorr00, SHORT* pKorr90,
SHORT* pNKorr00, SHORT* pNKorr90,
USHORT* pSamCnt);
Axis:
Number of the axis (0 to 15)
Latch:
0 = Output counter register 0
1 = Output counter register 1
pRefSta:
Pointer to a variable in which the REF status is
saved
pKorr00:
Pointer to a variable in which the compensated 0°
analog value is saved.
pKorr90:
Pointer to a variable in which the compensated 90°
analog value is saved.
pNKorr00:
Pointer to a variable in which the uncompensated
0° analog value is saved.
pNKorr90:
Pointer to a variable in which the uncompensated
90° analog value is saved.
pSamCnt:
Pointer to a variable in which the current number
of measuring points is saved for determining the
compensation value.
IK220DoRef
Starts reference-point traverse. The REF marks are evaluated as
defined in Parameter 6.
Prototype: BOOL
IK220DoRef (USHORT Axis);
Axis:
Number of the axis (0 to 15)
IK220CancelRef
Interrupts reference-point traverse.
Prototype: BOOL IK220CancelRef (USHORT Axis);
Axis:
Number of the axis (0 to 15)
IK220RefActive
Ascertains whether a REF function is running (Reset, Start or
Stop with REF or REF traverse).
Prototype: BOOL IK220RefActive (USHORT Axis,
BOOL* pStatus);
Axis:
Number of the axis (0 to 15)
pStatus:
Pointer to a variable in which the status is saved.
False (=0) = REF function not active
True
(
≠
0) = REF function active
