Specifications
124
Specifications
Mechanical Data
Dimensions Approx. 190 mm x 100 mm
Operating temperature – 0° C to 55° C (32 °F to 131 °F)
Storage temperature –30° C to 70° C (–22 °F to 158 °F)
Electrical data
Encoder inputs Two D-sub connections (15-pin male)
switchable:
• » 11 µA
PP
:
Sinusoidal current signals
Input frequency: max. 33 kHz
Cable length: max. 60 m
1)
• » 1 V
PP
:
Sinusoidal voltage signals
Input frequency: max. 500 kHz
Cable length: max. 60 m
1)
• EnDat
Cable length: max. 50 m
1)
• SSI
Cable length: max. 10 m
1)
External latch signals Assembly with two D-sub
(Option)
connections (9-pin, male)
2 inputs TTL levels
1 output TTL levels
Encoder outputs Sinusoidal current signals (11 µA
PP
)
(Option) Assembly with two D-sub
connections (9-pin, male)
Signal subdivision Up to 4096-fold
1)
With genuine HEIDENHAIN cables, please note the supply
voltage for the encoder.
