Operating Parameters
84
Parameter 11: Interval between two latches per timer. The
following values can be set directly by the timer of the IK 220:
Parameter
value
Time
interval
Parameter
value
Time
interval
17
100
µs
1)
33
1000
µs
18
150
µs
2)
34
1100
µs
19
200 µs
35
1200 µs
20
250 µs
36
1300 µs
21
300 µs
37
1400 µs
22
350 µs
38
1500 µs
23
400 µs
39
1600 µs
24
450 µs
40
1800 µs
25
500 µs
41
2000 µs
26
550 µs
42
2200 µs
27
600 µs
43
2400 µs
28
650 µs
44
2600 µs
29
700 µs
45
2800 µs
30
750 µs
46
3000 µs
31
800 µs
47
3200 µs
32
900
µs
Parameter 12: To permit a time interval of over 3.2 milli-
seconds, parameter 12 can realize a counter that uses only
every nth timer pulse for latching. To permit a latching interval
of 9 milliseconds, for example, parameter 11 must be set to 46
(corresponds to 3 milliseconds) and parameter 12 set to 3.
1)
Only possible without compensation of encoder signals and
without calculation of compensation values.
2)
With compensation; without calculation of compensation
values.
