Driver Software for WINDOWS
107
pSym0:
Pointer to a variable in which the symmetry of the
0° signal is saved
pSym90:
Pointer to a variable in which the symmetry of the
90° signal is saved
pFlag1:
Pointer to a variable in which flag 1 is saved
pFlag2:
Pointer to a variable in which flag 2 is saved
IK220GetCorrB
Reports the calculated compensation values of the IK 220.
Ascertainment of the compensation must first have been
enabled by parameter 9.
Prototype: BOOL IK220GetCorrB (USHORT Axis,
SHORT* pOfs0, SHORT* pOfs90,
SHORT* pPha0, SHORT* pPha90,
SHORT* pSym0, SHORT* pSym90,
USHORT* pFlag1, USHORT* pFlag2);
Axis:
Number of the axis (0 to 15)
pOfs0:
Pointer to a variable in which the offset of the 0°
signal is saved
pOfs90:
Pointer to a variable in which the offset of the 90°
signal is saved
pPha0:
Pointer to a variable in which the phase of the 0°
signal is saved
pPha90:
Pointer to a variable in which the phase of the 90°
signal is saved
pSym0:
Pointer to a variable in which the symmetry of the
0° signal is saved
pSym90:
Pointer to a variable in which the symmetry of the
90° signal is saved
pFlag1:
Pointer to a variable in which flag 1 is saved
pFlag2:
Pointer to a variable in which flag 2 is saved
IK220LoadCorrA
Loads the compensation value into the IK 220.
The compensation calculation must then be released by
Parameter 8.
Prototype: BOOL
IK220LoadCorrA (USHORT Axis,
SHORT Ofs0, SHORT Ofs90, SHORT Pha0,
SHORT Pha90, SHORT Sym0, SHORT Sym90);
Axis:
Number of the axis (0 to 15)
Ofs0:
Compensation value for offset of the 0° signal
Ofs90:
Compensation value for offset of the 90° signal
Pha0:
Compensation value for phase of the 0° signal
Pha90:
Compensation value for phase of the 90° signal
Sym0:
Compensation value for symmetry of the 0° signal
Sym90:
Compensation value for symmetry of the 90°
signal.
