4

CAN-Bus Telegramm

Fortsetzung

Informationsinhalte des CAN-Bus-Sende Telegramms (PDO 1)

Identifizier URZ 40a

180 (Hex) + Node ID

Byte 0

Ventil Iststellung in %

Byte

Ventil Sollstellung in %

Byte

Hysterese in %

Byte 3 Status

Bit 0 (0 x 0) Ventil Zufahren angesteuert
Bit  (0 x 0) Ventil Auffahren angesteuert
Bit  (0 x 04) Endlage Zu
Bit 3 (0 x 08) Endlage Auf
Bit 4 (0 x 0) Remotebetrieb
Bit 5 (0 x 0) Automatik (direkt mit Sonde)
Bit 6 (0 x 40) Handbetrieb
Bit 7 (0 x 80) Kalibrierbetrieb

(0 x 0 x) Sicherheitsstellung wird angefahren

Byte 4 Fehler

Bit 0 (0 x 0) TimeOut / BusOff
Bit  (0 x 0) Wegendschalter Plausibilität
Bit  (0 x 04) Antrieb blockiert
Bit 3 (0 x 08) Potentiometerfehler (Kabelbruch, Kurzschluss)
Bit 4 (0 x 0) Temperaturschwelle überschritten
Bit 5 (0 x 0) beide Tasten betätigt
Bit 6 (0 x 40) Kalibrierfehler
Bit 7 (0 x 80) 30 V nicht vorhanden

Byte 5

Temperatur im Gehäuse in °C

Byte 6: H

Byte 7: L

Gefilterter Potentiometer Rohwert

Informationsinhalte des CAN-Bus-Sende Telegramms (PDO 2)

Identifizier URZ 40a

280 (Hex) + Node ID

Byte 0: H

Byte : L

Kalibrierwert 0 %

Byte : H

Byte 3: L

Kalibrierwert 00 %

Byte 4: H

Byte 5: L

Gefilterter Potentiometer Rohwert

Byte 6

Temperaturschaltschwelle

Byte 7

TimeOut in 00 ms
