Installation
G&D CATVision-USB 2.0 · 4
Installation
Preparation
1. Please ensure to comply with the ambient temperature limit (see Technical Data
on page 12) in the surrounding of the device. The ambient temperature limit
must not be influenced by other devices.
2. Switch off the computer to be connected to the KVM extender and unplug the
monitor, keyboard and mouse cables from the interfaces.
3. Place the computer module (CATVision-CPU) in reach of the computer connec-
tion cable. The cable is available in three different lengths (2, 4 and 6 meters).
4. Place the user module (CATVision-CON) close to the remote console.
5. Take the supplied cables from the packing of the KVM extender and have them
available for installation.
Installing the computer module
The computer whose signals are transmitted to the remote console is connected to
the CATVision-CPU computer module. It is also possible to connect a local console
to the computer module.
ADVICE: Preferably connect the cables block by block and from bottom to top. This
way, already connected cables do not block the view at the interface descriptions.
