Technical Data
13 · G&D CATVision-USB 2.0
Individual features of the modules
CATVISION-ARU2-CPU | COMPUTER MODULE
Interfaces for
computer
Video:
via connection cable
1 × D-Sub HD 15 socket
PS/2 keyboard and mouse:
via connection cable
2 × PS/2 socket
USB:
1 × USB-B socket (keyboard/mouse data)
1 × USB-B socket (transparent)
Audio:
purchasable option
1 × 3,5-mm jack plug (Line In)
1 × 3,5-mm jack plug (Line Out)
RS232:
purchasable option
1 × D-Sub 9 socket
Interfaces for
local console
Video:
1 × D-Sub HD 15 socket
PS/2 keyboard and mouse: 2 × PS/2 socket
Interfaces to
user module
Mouse/Keyboard data:
1 × RJ45 socket
USB 2.0 devices:
1 × RJ45 socket
Casing
Material:
anodised aluminium
Dimensions (W x H x D):
270 × 44 × 210 mm
CATVISION-ARU2-CON | USER MODULE
Interfaces for
console
Monitor:
1 × D-Sub HD 15 socket
Keyboard:
1 × PS/2 socket
1 × USB-A socket
Mouse:
1 × PS/2 socket
1 × USB-A socket
USB 2.0 devices:
4 × USB-A socket (front panel)
Audio:
purchasable option
1 × 3,5-mm jack plug (Line In)
1 × 3,5-mm jack plug (Micro In)
1 × 3,5-mm jack plug (Speaker)
RS232:
purchasable option
1 × D-Sub 9 plug
Interfaces to
computer module
Mouse/Keyboard data:
1 × RJ45 socket
USB 2.0 devices:
1 × RJ45 socket
Casing
Material:
anodised aluminium
Dimensions (W x H x D):
270 × 44 × 210 mm
