Technical Data
G&D CATVision-USB 2.0 · 12
Technical Data
General features
CATVISION-USB 2.0 SERIES
Video
Signal type:
VGA (RGBHV, RGsB, RBGc)
Video resolution:
max. 1920 x 1440 @ 75 Hz
Video bandwidth:
250 MHz
Vertical frequency:
50 Hz to 150 Hz
Horizontal frequency:
30 kHz to 135 kHz
Range:
max. 300 meters
USB 2.0
Transmission type:
transparent
Transmission rate:
up to 480 Mbit/s
Supported devices:
High-Power-Devices (up to 500 mA)
Range:
max. 100 meters
Audio
purchasable option
Transmission type:
transparent, bidirectional
Resolution:
18 bit, digital
Microphone preamplification: 20 db
Sampling rate:
48 kHz
Bandwidth:
22 kHz
RS232
purchasable option
Transmission type:
transparent
Transmitted signals:
RxD, TxD, RTS, CTS, DTR, DSR
Transmission rate:
max. 57.600 bit/s (up to 100 meters);
max. 38.400 bit/s (up to 200 meters)
Main power supply
Type:
internal power pack
Connection:
IEC plug(IEC-320 C14)
Voltage:
AC 100-240 V/60-50 Hz
Redundant
power supply
Type:
eExternal power pack
Connection:
miniDIN-4 Power socket
Voltage:
+12 VDC
Operating environment Temperature:
+5 to +40 °C
Air humidity:
< 80%, non-condensing
Conformity
CE, RoHs
