The »DVIMUX4-DL-USB« KVM switch
2 · G&D DVIMUX4-DL-USB
The »DVIMUX4-DL-USB« KVM switch
The DVIMUX4-DL-USB KVM switch enables you to operate up to four computers
via one console.
The console has to be supplied with a USB keyboard, a USB mouse and a digital
and/or analog monitor. The computers connected to the KVM switch are operated
at the installed console.
The switching between computers takes place either via the pushbuttons on the
front panel, configurable key combinations, or a serial device which is connected to
the Service port.
The front panel of the device provides two USB 2.0 interfaces to operate any USB
devices. The connected USB devices are available to whichever active computer.
After enabling the USB hold function (see page 31), the USB devices can be perma-
nently switched to a defined computer (see page 12). The switching of the USB
devices remains the same when switching the KVM channel.
Package contents
 1 × DVIMUX4-DL-USB KVM switch (basic or multi-channel variant)
 1 × DVI-Divider adapter per supported video channel
 1 × data cable (Update-Cable-2)
 1 × power cable
 1 × »Installation and Operation« manual
NOTE: The KVM switch emulates keyboard and mouse on each channel and
hence guarantees error-free booting at all times.
IMPORTANT: KVM cable sets are required to connect the computers to the KVM
switch. A list of the available KVM cable sets can be found on page 32.
