Configuration
G&D DVIMUX4-DL-USB · 27
English
Changing the standard mode of the Service port
The Service port of the KVM switch can be used both for operating the setup menu
and for switching the channels with a serial device.
The Setup Menu mode is enabled in the default settings of the KVM switch. In this
mode, the Setup Menu is immediately displayed in the terminal emulator after a ses-
sion is established with the KVM switch.
If you primarily use the Service port for switching the active channel via a serial device,
it is recommendable to enable the Switch mode.
How to choose the mode which is to be enabled when booting the KVM exten-
der:
IMPORTANT: Depending on the purpose of use, the KVM extender distinguishes
between the modes listed below.
ADVICE: The activated mode when starting the KVM extender can be changed
anytime during operation:

By entering the » #! « command, the KVM switch changes to the Setup menu mode.
 By entering the » ! « command, the KVM switch changes to the Switch mode
Setup M
en
u 1. Use the terminal emulator to establish a connection to the KVM switch.
If the setup menu is not displayed, the Switch mode of the service port is
enabled. Enter » #! « to switch to the setup menu.
2. Use the Arrow or Arrow keys to select the Service RS232 Startup Mode entry.
3. Press the Space key (repeatedly) to choose between the following options:
Setup Menu  enables Setup Menu mode when starting KVM extender
Switch  enables Switch mode when starting KVM extender
4. Press the S key to save your settings.
