Configuration
G&D DVIMUX4-DL-USB · 13
English
Configuration
The configuration of the KVM switch can optionally be changed in the setup mode
or in the setup menu:
 Enable the setup mode using the console keyboard. You can change the configura-
tion via special setup keys.
 The setup menu is operated with a terminal emulator and provides a user interface
to configure the device.
Overview of the functions and default settings
The following table lists functions that can be configured as well as their default set-
tings of the KVM switch.
Detailed description of the functions is given in the following pages:
Basic operation of the setup mode as well as the setup menu is explained in the fol-
lowing pages.
All functions that can be configured for the KVM switch are described in detail from
page 17 on.
NOTE: The USB keyboard type (see page 28) can only be selected in the setup menu
where you can also find the configuration settings of the KVM switch.
Function Default Page
Using single or double hotkeys single hotkeys 17
Changing the single hotkey Ctrl 18
Changing the double hotkey Ctrl+Shift 19
Changing the select keys 1 to 4 20
Enabling/Disabling the hotkey delay 7 seconds 21
Resetting the defaults 22
Auto-accessing the first channel disabled 23
(De)activating the switching via front buttons enabled 23
(De)activating the switching via hotkeys enabled 24
(De)activating the switching via step keys disabled 25
Changing the bitrate of the Service port 115.200 26
Changing the standard mode of the Service port switch 27
Selecting the USB keyboard type PC Multimedia 28
Enabling/Disabling USB 2.0 data transmission enabled 30
USB pinning disabled 31
