Configuration
26 · G&D DVIMUX4-DL-USB
Changing the bitrate of the Service port
The Service port of the KVM switch can be used both for operating the setup menu
and for switching the channels with a serial device.
The Service port transfers a certain amount of data per time unit. The bitrate is given
in bit/s.
If the bitrate cannot be adjusted to the standard bitrate of the KVM switch (115.200
bit/s) in the terminal emulator or the serial device, the bitrate of the Service port can
be modified.
How to select the bitrate of the Service port of the KVM switch:
IMPORTANT: Transmitter and receiver of the data must use the same bitrate to
ensure successful communication between the terminal emulator or a serial device
and the KVM switch.
Setup Men
u 1. Use the terminal emulator to establish a connection to the KVM switch.
If the setup menu is not displayed, the Switch mode of the service port is
enabled. Enter » #! « to switch to the setup menu.
2. Use the Arrow or Arrow keys to select the Service RS232 Bitrate entry.
3. Press the Space key (repeatedly) to choose between the following bitrates:
115200  serial data transmission with 115.200 bit/s
9600  serial data transmission with 9.600 bit/s
4. Press the S key to save your settings.
