Installation
6 · G&D DVIMUX4-DL-USB
Connecting the power supply
Power: Connect the power cable (PowerCable-2 Standard) to a power outlet and the
power socket of the KVM switch.
Figure 4: Interface to connect the power supply
Monitor 1
Keyb./Mouse Speaker
CON
Line In
Power
Line In USB 2.0 Line Out
CPU 3
DVI-I CPU 3.1
Line In USB 2.0 Line Out Line In USB 2.0 Line Out
CPU 4
DVI-I CPU 4.1
CPU 1
DVI-I CPU 1.1
Line In USB 2.0 Line Out
CPU 2
DVI-I CPU 2.1
