Technical data
34 · G&D DL-MUX4
Specific features
Casing
Material:
anodised aluminium
Dimensions (W × H × D):
see specific features
Weight:
see specific features
Operating environment Temperature:
see specific features
Air humidity:
< 80%, non-condensing
Conformity
CE, RoHs
DL-MUX
No. of video sources
per computer/console:
1
Interfaces
for console
Video:
1 × DVI-I socket
Interfaces
per computer
Video:
1 × DVI-I socket
Current consumption
max.:
100-240VAC/60-50Hz, 0.4-0.2A
Power consumption
Standby:
7,0 W @ 240 VAC; 6,4 W @ 100 VAC
Operation:
21,8 W @ 240 VAC; 21,7 W @ 100 VAC
Casing
Dimensions (W × H × D):
435 × 44 × 210 mm
Weight:
approx. 2,3 kg
Operating environment Temperature:
+5 to +45 °C
DL-MUX-MC2
No. of video sources
per computer/console:
2
Interfaces
for console
Video:
2 × DVI-I socket
Interfaces
per computer
Video:
2 × DVI-I socket
Current consumption
max.:
100-240VAC/60-50Hz, 0.5-0.2A
Power consumption
Standby:
9,3 W @ 240 VAC; 8,8 W @ 100 VAC
Operation:
25,8 W @ 240 VAC; 26,3 W @ 100 VAC
Casing
Dimensions (W × H × D):
435 × 66 × 210 mm
Weight:
approx. 2,7 kg
Operating environment Temperature:
+5 to +45 °C
