Steckerbelegung Baugruppe GPS170
a c
1 VCC in (+5V) VCC in (+5V)
2 VCC in (+12V) VCC in (+12V)
3 VDD in (TCXO/OCXO) VDD in (TCXO/OCXO)
4 (reserved, FreqAdjust out)
5 FIXED FREQUENCY out (reserved in-3)
6 (reserved in-1) PPS out
7 (reserved in-2)
8 (reserved, 10 MHz_OSC in) PPM out
9 10 MHz SINE out (OCXO MQ/HQ) /RESET in/out
10 100 kHz out ProgPulse0 out
11 1 MHz out ProgPulse1 out
12 10 MHz out ProgPulse2 out
13 TIME CODE DC out
14 TIME CODE AM out
15 COM2 RxD in
16 COM2 TxD out (reserved, P7.5)
17 COM3 RxD in DCF_MARK out
18 COM3 TxD out (reserved, Vref/TxD2 TTL)
19 GND TIME_SYN out
20 GND (reserved, P7.6)
21 GND F_SYNTH out
22 GND F_SYNTH_OD out
23 GND F_SYNTH_SIN out
24 GND COM1 TxD out
25 GND
26 GND COM0 TxD out
27 GND CAP1 in
28 GND CAP0 in
29 GND COM1 RxD in
30 GND COM0 RxD in
31 GND GND
32 GND GND
NEW SIGNALS compared to GPS167 (reserved, not imlemented yet)
Steckerleiste nach DIN 41612, Typ C 64, Reihen a + c
