58
Kurzübersicht GPS170LCD-MP Bedienung
NEXT
CLR/ACK
M
E
N
U
N
E
X
T
Meinberg GPS170 S/N: 0290100xxx70
REV:1.xx LCD_2 GPS: NORMAL OPERATION Mon, DD.MM.YYYY
UTC 12:00:00
RECEIVER POSITION
Lat:51°59’06’’N Lon: 9°13’30’’E Al:110m RECEIVER POSITION
Lat: 51.9851° Lon: 9.2253° Al: 110m
RECEIVER POSITION
x: 3885422m y: 631059m z: 5001868m
SATELLITE CONSTELLATION
In view: 9 Good: 8 Sel: 3 19 26 13 DILUTION OF PRECISION
PDOP: 4.33 TDOP: 2.88 GDOP: 5.20
SATELITE 4 INFO: El: 17° AZ: 204°
Dist: 24000 km Dopp: -3.550 kHz
USER CAP0
UTC DD.MM.YYYY 12:00:00.1234567 USER CAP1
NA
SETUP: ENABLE OUTPUTS Serial: if sync Pulses: if sync
Synth: if sync
SETUP: TIME ZONE DAYLIGHT SAVING OFF: !MEZ ! +01:00h
DAYLIGHT SAVING ON : !MESZ ! +02:00h
SETUP: DAYLIGHT SAV ON DAYLIGHT SAV ON Date: 25.03.****
Day Of Week: SUN Time: 2:00:00
SETUP: DAYLIGHT SAV OFF DAYLIGHT SAV OFF Date: 25.10.****
Day Of Week: SUN Time: 3:00:00
SETUP: SERIAL PORT PARMS COM0: 19200 8N1 COM1: 9600 8N1
COM2: 9600 7E2 COM3: 9600 7E2
SETUP: SER. STRING TYPE
SETUP: SER. STRING MODE
COM0: Meinbg Std
COM1: Capture
COM0: Per Second COM1: Cap.Events
COM2: Per Second COM3: Per Second
SETUP: INITIAL POSITION INITIAL POSITION
Lat:51°59’06’’N Lon: 9°13’30’’E Al:110m
SETUP: INITIAL TIME SET INITIAL TIME MESZ
Date:
Time: 12:00:00 DD.MM.YYYY
SETUP: INIT USER PARMS Are you sure ? Press ...
INC => YES MENU => NO
Are you sure ? Press ...
INC => YES MENU => NO
Are you sure ? Press ...
INC => YES MENU => NO
SETUP: INIT GPS PARMS
SETUP: FORCE BOOT MODE
SETUP: ANTENNA CABLE SETUP: ANTENNA CABLE
LENGTH: 0020 m
