6
opening and locking
The indicated turning direction
applies when the central bar is
held firm and the ends are turned
as indicated. Once the bar is
lightly fixed into the doorframe,
only the central part can be turned and the turning direction is reversed. Tighten the door
exercise bar until it can no longer be moved when a tugging load is applied (Note that a
deformation of the doorframe may occur despite following the instructions correctly)!
The rubber surfaces at the ends of the door exercise bar must always rest completely on
the sides of the doorframe.
Installation with safety brackets
Caution! The use of the safety brackets is absolutely essential for exercises with the
expanders.
- Be careful when locking the door exercise bar into the doorframe that the brackets are
positioned directly opposite the direction in which the expanders will be pulled
(Illustration D).
- Unscrew the red cap (Illustration A).
- Place the supplied safety brackets on the door exercise bar (Illustration B).
- Screw the safety brackets on to the black end cap and screw both parts back together.
Do not screw up tightly because the safety brackets must be able to turn freely for later
installation into the doorframe. Insert the end cap with the safety bracket back onto the
door exercise bar (Illustration C).
- After locking the door exercise bar into the doorframe, tighten the screws of the safety
brackets firmly.
tools required
To screw the door exercise bar into the doorframe, you will need a crosshead screwdriver
and a suitable corresponding drill.
B D A c
Lock in position Open
Open
Lock in position
Open
Lock in position
