Introduction
Vacuum base vice
Q
Introduction
The instructions for use are to be considered as part of the
product. They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information and
instructions for use. The product must only be used as described
and for the stated fields of application. If you pass the product on
to third parties, please give them all of the documentation as well.
Q
Intended Use
The product is intended for clamping small workpieces to allow them
to have further work performed upon them. Other uses or changes
to the product are considered to be contrary to the intended use
and may harbour risks of injury and damage. The manufacturer
does not accept any liability for injury or damage resulting from
use of this product contrary to its intended use. The product is not
intended to be used for commercial purposes.
Q
Description of parts and features
1
Jaw protectors
2
Jaws with V-grooves
3
Vice jaws tommy bar
4
Spindle
5
Suction pad lever
6
Ball joint
7
Suction pad
8
Ball joint tommy bar
