Designated Use
The oil filter wrench PAWO 12 A1 is intended for the
loosening and tightening of oil filters fitted in automobiles.
Technical data
Length: 215 mm
Width of steel band: 12 mm
Using the oilfilter wrench

Note: Oil changes are always to be carried out at
the motor operating temperature.
Precautionary measures for avoiding burns when
removing hot oil
• when oil is being drained from a still hot engine, all
contact with the oil itself is to be avoided.
• the new oil filter is to be filled up to 2/3 with fresh
oil and the rubber seal to be smeared with oil. This
smearing of the rubber seal facilitates later removal
of the oil filter and helps prevent damage to the seal
when tightening.
• screw the oil filter on hand-tight, then secure it firmly
with the oil filter key.

Important: Observe without exception the
pertinent details given in the operating instructions
for your vehicle.
• The oil filter can be exchanged after the oil has been
drained and the sump sealing screw replaced.
• Place the oil filter key over the oilfilter and secure it
by turning the adjustment screw.
• Loosen the oilfilter with the oil filter key, then
remove it by hand.

Important: A residual amount of oil will escape
from the area of the filter mounting and filter. Ensure
that an oil pan is appropriately positioned.
