Powerfix Z16531 - Handbuch (Seite 7)

5 GB/IE
Introduction
Hand-held stapler set
Q
Proper Use
The stapler gun is intended exclusively for stapling
cardboard, leather, cloth (textile or natural fibres)
or similar lightweight materials on to hardwood, soft-
wood, chipboard or similar plywood-type materials.
The product is not intended for commercial use.
Q
Description of parts
1 Operating handle
2 Staple pusher
3 Hook
4 Magazine
5 Side wing
6 Staple eject opening
7 Adjusting screw
Q
Included items
1 x Stapler gun
500 x Flat crown staples (8 mm)
500 x Round crown staples (12 mm)
500 x T-nails (10 mm)
1 x Operating instructions
Q
Staples / nails
Note: The precision components of the device are
designed to use the following standard, widely
available staples and nails:
Type
A
(mm)
B
(mm)
C
(mm)
Flat crown
staples
B
A
C
4 - 14 11.2 - 11.5 1.1 - 1.3
Round crown
staples
B
A
C
10 - 12 6.2 - 6.5 1.1 - 1.3
T-nails
B
A
C
10 - 14 1.6 - 2 1.1 - 1.3
Safety advice
Keep all the safety advice and instruc-
tions in a safe place for future refer-
ence!
J Always keep the product out of reach of children.
Children often underestimate danger. Store the
device indoors in an enclosed, dry place where
it cannot be reached by children.
J Ensure that staples and nails cannot under any
circumstances strike people or animals. Failure
to observe this advice may lead to injury.
J Wear personal protective equipment and always
wear safety glasses. This also applies to people
who may be helping with the work by support-
ing or holding the workpiece.
CAUTION! Do not support yourself with your
hands under any circumstances near or in front
the stapler gun or on the surface being tacked.
One slip may result in injury.
J Every time before you use the device, check
that it is in perfect condition. Damage to any of
