23 PDS 45 A1
GB
NOTICE
► Check the contents to ensure everything is available and for
signs of visible damage.
► If the delivery is not complete or is damaged due to defective
packaging or through transportation, contact the Service Hotline
(see chapter Service).
Component description
Release button
Switching lever
Main scale
Ring scale
Rotatable hand-grip
Locking screw
Socket 21 mm
Socket 19 mm
Socket 17 mm
Extension piece 125 mm
Technical data
Drive ½“
Adjustable torque range 28 - 210 Nm
Actuation accuracy ± 4 % of Scale value
Length approx. 45 cm
Weight approx. 1360 g
