12 GB/IE
Before Initial Use / Use
Attaching the repair device
Push the fixing clamp
11
onto the mounting rod
10
, set
the desired height and tighten the fastening screw
12
clockwise.
Insert the ball joint of the repair device
15
into the
corresponding recess of the fixing clamp
11
.
Fix the repair device
15
in place by tightening the fasten-
ing screw
16
clockwise.
Mounting the magnifying glass
Push the fixing clamp
7
on to the mounting rod
10
and
set the desired height. Tighten the fastening screw
8
by
turning it clockwise.
Insert the ball joint
5
into the corresponding recess
and tighten the fastening screw
6
for the ball joint
5
clockwise (Fig. A).
Use
Using the Precision Engineer’s LED
Magnifying Glass
Turn the retaining screws
19
on the alligator clips
18
in a
clockwise direction. Clamp the item to be repaired with
the alligator clips
18
in the repair device
15
.
