BECKHOFF CX2100­09x4 - Handbuch (Seite 72)

Inbetriebnahme
Voraussetzungen
Entwicklungsumgebung Zielplattform USV­Hardware Einzubindende SPS­
Bibliotheken
TwinCAT v2.8.0, Build >
745 TwinCAT v2.9.0,
Build > 945 PC (i386) • Beckhoff P24Vxxxx USV;
• Integrierte Beckhoff
Industrie­PC 24V USV an
der CP903x­Karte (PCI/
ISA);
• Die mit Beckhoff Industrie­
PC ausgelieferten APC­
Geräte die das
Smartprotokoll unterstützen
und mit dem Windows USV­
Dienst konfiguriert werden
können.
TcIoFunctions.Lib
( Standard.Lib;
TcBase.Lib;
TcSystem.Lib;
TcUtilities.Lib werden
automatisch
eingebunden )
5.3.2 ST_UPSStatus
TYPE ST_UPSStatus
STRUCT
Vendor : STRING; (* Reports the UPS vendor name as displayable string. *)
Model : STRING; (* Reports the UPS model name as displayable string. *)
FirmwareRev : STRING; (* Reports the UPS firmware revision as a displayable string. *)
SerialNumber : STRING; (* Reports the UPS serial number as a displayable string. *)
BatteryLifePercent : DWORD; (* The percent of battery capacity remaining in the UPS,
represented as a value in the range of 0 through 100. *)
BatteryLifeTime : DWORD; (* The amount of remaining UPS run time, in minutes.
*)
eBatteryStatus : E_BatteryStatus; (* The current status of the UPS batteries. *)
eCommStatus : E_UpsCommStatus; (* The status of the communication path to the UPS. *)
ePowerStatus : E_UpsPowerStatus; (* Reports the status of utility­supplied power into the
UPS. *)
nPowerFailCnt : DWORD; (* Power fail counter. Increments every time the UPS ser­
vice detects power fail. *)
dwChargeFlags : DWORD; (* Most reserved for future use.
Battery charge status flags. This member can be one or more of the following values.
0: Unknown status (all bits set to 0)
1: High (bit 0 is set)
2: Low (bit 1 is set)
4: Critical (bit 2 is set)
8: Charging (bit 3 is set)
­ ­ (bits 4 ­ 6 reserved)
128: No battery (bit 7 is set)
256: UPS fan error (bit 8 is set)
­ ­ (bits 9 reserved)
1024: Service interval message (bit 10 is set)
­ ­ (bits 11 ­ 31 reserved)
*)
END_STRUCT
END_TYPE
Nicht alle USV­Modelle können alle Statusinformationen liefern.
X : Die Statusinformation ist bei diesem Model vorhanden.
