HPI Racing D8T - Handbuch (Seite 22)

22
7mm 7mm
9mm 9mm 9mm 9mm
C 05
C 04
Z700
Set Screw M3x3mm
Madenschraube M3x3mm
Vis sans tête M3x3mm
イモネジM3x3mm
Z352
Button Head Screw M3x8mm
Inbus-flachkopfschraube M3x8mm
Vis tête ronde M3x8mm
ナベネジ M3x8mm
Z224
Washer M3x8mm
Unterlagscheibe M3x8mm
Rondelle M3x8mm
ワッシャーM3x8mm
Z653
Nut M3
Mutter M3
Écrou M3
ナットM3
HBC8050
Screws 3x14mm
Schraube M3x14mm
Vis M3x14mm
スクリュー M3x14mm
Z351
Button Head Screw M3x6mm
Inbus-flachkopfschraube M3x6mm
Vis tête ronde M3x6mm
ナベネジ M3x6mm
Montage de la paroi centrale
センターバルクの組立て
Center Bulk Assembly
Montage der mittleren Differentialgehäuse
20
21 Montage du frein
ブレーキの組み立て
Brake Assembly
Montage der Bremse
x4
HBC8050
HBC8050
HBC8050
HBC8050
Z700
Z351
Z224
Z653
Z352
Z352
Z352
Z352
Z700
67473
67473
67472
67472
67821
67422
HBC8048
HBC8048
HBC8048
HBC8048
67421
67421
67419
67419
x4
x1
x2
x1
x1
