Pièces métalliques
メタルパーツ
Metal Parts
Metall Teile
Shown actual size
In Originalgröße abgebildet
Taille réelle
原寸大
1 : 1
94388
Cap Head Screw M3x16mm
Inbusschraube M3x16mm
Vis tête cylindrique M3x16mm
キャップネジ M3x16mm
94505
Cap Head Screw M4x12mm
Inbusschraube M4x12mm
Vis tête cylindrique M4x12mm
キャップネジ M4x12mm
94531
Flat Head Screw M4x15mm
Flachkopfschraube M4x15mm
Vis tête plate m4x15mm
サラネジ M4x15mm
94554
Button Head Screw M4x10mm
Flachkopfschraube M4x10mm
Vis tête ronde M4x10mm
ナベネジ M4x10mm
94675
Cap Head Screw M3.5x14mm
Inbusschraube M3.5x14mm
Vis tête cylindrique M3.5x14mm
キャップネジ M3.5x14mm
94676
Cap Head Screw M3.5x18mm
Inbusschraube M3.5x18mm
Vis tête cylindrique M3.5x18mm
キャップネジ M3.5x18mm
94677
Cap Head Screw M3.5x42mm
Inbusschraube M3.5x42mm
Vis tête cylindrique M3.5x42mm
キャップネジ M3.5x42mm
100550
Pan Head Screw M5x8mm
Flachkopfschraube M5x8mm
Vis tête cylindrique M5x8mm
バインドネジ M5x8mm
Z084
Flat Head Screw M3x12mm
Senkkopfschraube M3x12mm
Vis tête plate M3x12mm
サラネジ M3x12mm
Z086
Flat Head Screw M3x18mm
Senkkopfschraube M3x18mm
Vis tête plate M3x18mm
サラネジ M3x18mm
Z242
E Clip E2mm
E-Clip E2mm
Circlips 2mm
EリングE2
Z663
Lock Nut M3
Stoppmutter M3
Contre-écrou M3
ロックナットM3
Z700
Set Screw M3x3mm
Madenschraube M3x3mm
Vis sans tête M3x3mm
イモネジM3x3mm
Z740
Set Screw M5x4mm
Madenschraube M5x4mm
Vis sans tête M5x4mm
イモネジM5x4mm
100551
Lock Nut M2.5
Stoppmutter 2.5mm
Écrou de blocage 2.5mm
ロックナット 2.5mm
100553
Washer M2.9x8x0.5mm
Scheibe 2.9x0.5mm
Rondelle 2.9x8x0.5mm
ワッシャー 2.9x8x0.5mm
100554
Set Screw M3x14mm
Madenschraube M3x14mm
Vis sans tête M3x14mm
イモネジM3x14mm
100555
Set Screw M4x3mm
Madenschraube M4x3mm
Vis sans tête M4x3mm
セットスクリューM4x3mm
100556
Flat Head Screw M3x14mm
Senkkopfschraube M3x14mm
Vis tête plate M3x14mm
サラネジ M3x14mm
100557
Flat Head Screw M3x16mm
Senkkopfschraube M3x16mm
Vis tête plate M3x16mm
サラネジ M3x16mm
100558
Button Head Screw M3x4mm
Flachkopfschraube M3x4mm
Vis tête ronde M3x4mm
ナベネジ M3x4mm
100559
Button Head Screw M3x14mm
Flachkopfschraube M3x14mm
Vis tête ronde M3x14mm
ナベネジ M3x14mm
HBC8050
Screws 3x14mm
Schraube M3x14mm
Vis M3x14mm
スクリュー M3x14mm
Z083
Flat Head Screw M3x10mm
Senkkopfschraube M3x10mm
Vis tête plate M3x10mm
サラネジ M3x10mm
Z087
Flat Head Screw M3x20mm
Senkkopfschraube M3x20mm
Vis tête plate M3x20mm
サラネジ M3x20mm
Z216
Button Head Screw M3x15mm
Inbus-flachkopfschraube M3x15mm
Vis tête ronde M3x15mm
ナベネジ M3x15mm
Z224
Washer M3x8mm
Unterlagscheibe M3x8mm
Rondelle M3x8mm
ワッシャーM3x8mm
Z307
Flat Head Screw M4x10mm
Senkkopfschraube M4x10mm
Vis tête plate M4x10mm
サラネジ M4x10mm
Z351
Button Head Screw M3x6mm
Inbus-flachkopfschraube M3x6mm
Vis tête ronde M3x6mm
ナベネジ M3x6mm
Z352
Button Head Screw M3x8mm
Inbus-flachkopfschraube M3x8mm
Vis tête ronde M3x8mm
ナベネジ M3x8mm
Z353
Button Head Screw M3x10mm
Inbus-flachkopfschraube M3x10mm
Vis tête ronde M3x10mm
ナベネジ M3x10mm
Z354
Button Head Screw M3x12mm
Inbus-flachkopfschraube M3x12mm
Vis tête ronde M3x12mm
ナベネジ M3x12mm
Z357
Button Head Screw M3x20mm
Inbus-flachkopfschraube M3x20mm
Vis tête ronde M3x20mm
ナベネジ M3x20mm
Z542
Cap Head Screw M3x8mm
Inbusschraube M3x8mm
Vis tête cylindrique M3x8mm
キャップネジ M3x8mm
Z544
Cap Head Screw M3x12mm
Inbusschraube M3x12mm
Vis tête cylindrique M3x12mm
キャップネジ M3x12mm
Z547
Cap Head Screw M3x20mm
Inbusschraube M3x20mm
Vis tête cylindrique M3x20mm
キャップネジ M3x20mm
Z548
Cap Head Screw M3x22mm
Inbusschraube M3x22mm
Vis tête cylindrique M3x22mm
キャップネジ M3x22mm
Z653
Nut M3
Mutter M3
Écrou M3
ナットM3
Z664
Lock Nut M4
Stoppmutter M4
Contre-écrou M4
ロックナットM4
Z721
Set Screw M4x4mm
Madenschraube M4x4mm
Vis sans tête m4x4mm
イモネジM4x4mm
Z725
Set Screw M4x10mm
Madenschraube M4x10mm
Vis sans tête m4x10mm
イモネジM4x10mm
Z800
Spring Washer 3x6mm
Federscheibe 3x6mm
Rondelle elastique 3x6mm
スプリングワッシャー3x6mm
66796
Shock Mount Screw (CW)
Daempfer Befestigungsschraube (CW)
Vis de montage amortisseur (CW)
ショックマウントスクリュー（右ネジ）
66796
Shock Mount Screw (CCW)
Daempfer Befestigungsschraube (CCW)
Vis de montage amortisseur (CCW)
ショックマウントスクリュー（左ネジ）
67470
Washer 5x8x0.5mm
Scheibe 5x8x0.5mm
Rondelle 5x8x0.5mm
ワッシャー5x8x0.5mm
Z704
Set Screw M3x8mm
Madenschraube M3x8mm
Vis hallen sans tete M3x8mm
イモネジM3x8mm
Z702
Set Screw M3x5mm
Madenschraube M3x5mm
Vis hallen sans tete M3x5mm
イモネジM3x5mm
Z492
TP. Binder Head Screw M2.2x4.8mm
Flachkopfschneidschraube M2.2x4.8mm
Vis TP. Tole tete plate M2.2x4.8mm
T.P バインドネジ M2.2x4.8mm
2
Parts Reference
Übersicht aller Teile
Référence des pièces
パーツ図
