46
5
Parts List
Ersatzteileliste
Liste de pièces
パーツリスト
En
Parts # Qty Description
Parts List
67625
2
DIFF MOUNT SPACERS
67803
1
CENTER DRIVE SHAFT COUPLING (REAR/D8T)
67804
2
WHEEL HEX HUB 6.7MM (BLACK)
67805
1
DRIVE SHAFT 131MM
67806
2
TURN BUCKLE 4X100MM
67808
2
FRONT SUSPENSION ARM (D8T)
67809
2
REAR SUSPENSION ARM (D8T)
67810
1
REAR SHOCK TOWER (D8T)
67815
1
FRONT SHOCK TOWER (D8T)
67817
1
FUEL TANK SET (D8T)
67819
1
LIGHTWEIGHT MAIN CHASSIS (4MM/HARD ANODIZED/D8T)
67820
4
SHOCK END (LONG)
67821
1
CENTER DIFF MOUNT COVER (D8T)
67822
4
BODY MOUNT SET (D8T)
67824
1
FRONT CENTER DRIVE SHAFT SET
67825
1
HB D8T BODY (CLEAR)
67826
1
UNIVERSAL DRIVE SHAFT SET (131MM)
67827
4
HB T-DISH WHEELS (WHITE)
67828
1
HB D8T BODY/WING DECAL
50474
1
SILICONE TUBE 2X5X300MM
66796
4
SHOCK MOUNT SCREW (X2 CW/ X2 CCW)
67289
2
BIG BORE SHOCK BODY (16X107MM)
67292
2
SHOCK SHAFT 4X112MM
67344
1
AIR FILTER BOOT
67345
1
AIR FILTER SET
67347
1
AIR FILTER FOAM SET (INNER/OUTER)
67350
8
SHOCK BOOTS SET
67351
1
SHOCK END/SHOCK SPRING RETAINER SET
67353
1
6 HOLES SHOCK PISTON SET (6HOLES/1.2,1.3,1.4MM)
67356
2
STONE GUARD SET (RIGHT/LEFT)
67364
1
FUEL TANK STAND-OFF AND FUEL LINE CLIPS SET
67366
1
ENGINE MOUNT SET
67367
2
ENGINE MOUNT
67368
1
RADIO TRAY SET
67376
1
SERVO ARM SET
67378
1
SERVO HORN SET
67379
1
PIVOT PLATE (RR/3DEG)
67380
1
PIVOT PLATE (RF/3DEG)
67382
1
REAR CHASSIS STIFFENER MOUNT
67383
1
REAR CHASSIS STIFFENER
67384
1
FRONT SUSPENSION BLOCK (FR)
67386
2
FRONT HUB CARRIER SET (RIGHT/LEFT/10DEG)
67388
2
FRONT SPINDLE SET (RIGHT/LEFT)
67390
4
KING PIN BUSHING
67391
1
FRONT SUSPENSION BLOCK (FF)
67392
2
STEERING POST
67397
1
STEERING CRANK SET
67398
1
STEERING PLATE
67399
2
STEERING BUSHING
67400
1
STEERING BRACE
67401
1
FRONT CHASSIS STIFFENER
67402
1
AXLE
67404
2
UNIVERSAL JOINT REBUILD KIT
67406
1
CENTER DRIVE SHAFT COUPLING
67407
1
CENTER DRIVE SHAFT (78MM)
67410
2
SHOCK STAND OFF
67415
2
SUSPENSION SHAFT 4X71MM SILVER (FRONT/INNER)
67416
2
SUSPENSION SHAFT 3X43MM SILVER (FRONT/OUTER)
67417
2
SUSPENSION SHAFT 4X68MM BLACK (REAR/INNER)
67418
2
SUSPENSION SHAFT 3X44MM BLACK (REAR/OUTER)
67419
2
DIFFERENTIAL MOUNT
67421
2
BRAKE DISK ROTOR
67422
1
AIR FILTER BRACE
67424
1
FUEL TANK COUPLER AND NUT
67426
1
FUEL FILTER
67433
2
BIG BORE SHOCK CAP
67435
2
BIG BORE SHOCK BODY (16X97MM)
67436
2
SHOCK SHAFT 4X97MM
67438
2
BALL BEARING 8X14X4MM
67447
2
BIG BORE SHOCK SPRING (WHITE/60MM/81GF)
67448
2
BIG BORE SHOCK SPRING (BLUE/60MM/89GF)
67455
2
BIG BORE SHOCK SPRING (BLUE/76MM/63GF)
67468
1
EXHAUST HANGER WIRE
67470
6
WASHER 5X8X0.5MM
67472
2
BRAKE CAM
67473
2
BRAKE WIRE
67491
2
STEERING LINKAGE
67492
4
17MM WHEEL NUT (BLACK)
67493
4
BALL 6MM
67499
1
SPIRAL PINION GEAR 10 TOOTH
67510
1
SWAY BAR (2.8MM)
67511
1
SWAY BAR (2.4MM)
67514
6
SPACER 3X8.5X3MM
67515
2
BIG BORE SHOCK MAINTENANCE SET
67516
8
BALL END SET
67520
1
THROTTLE LINKAGE SET
67521
1
WING MOUNT SET
67525
1
FLYWHEEL (3PINS/HARD BLACK)
67528
2
BIG BORE SHOCK SPRING ADJUST NUT (BLACK)
67529
2
BIG BORE SHOCK BOTTOM CAP BLACK
67531
1
CNC PIPE MOUNT (BLACK)
67534
4
BALL 5.8X5.6MM
86598
10 WASHER 13X16X0.2MM
94388
10 CAP HEAD SCREW M3X16MM
94505
10 CAP HEAD SCREW M4X12MM
94531
10 FLAT HEAD SCREW M4X15MM (HEX SOCKET)
94554
10 BUTTON HEAD SCREW M4X10MM (HEX SOCKET)
94675
8
CAP HEAD SCREW M3.5X14MM
94676
8
CAP HEAD SCREW M3.5X18MM
94677
8
CAP HEAD SCREW M3.5X42MM
100550
10 PAN HEAD SCREW M5X8MM
100551
4
LOCK NUT 2.5MM
100553
8
WASHER 2.9X8X0.5MM
100554
4
SET SCREW M3X14MM
100555
4
SET SCREW M4X3MM
100556
10 FLAT HEAD SCREW M3X14MM (HEX SOCKET)
100557
8
FLAT HEAD SCREW M3X16MM
100558
10 BUTTON HEAD, SOCKET, M3X4MM
100559
10 BUTTON HEAD SCREW M3X14MM (HEX SOCKET)
100560
10 BUTTON HEAD SCREW M3X16MM (HEX SOCKET)
B121
2
BALL BEARING 5X10X4MM (RUBBER SHIELD)
HB70545
6
BODY CLIP, MED. 6MM
HBC8003 1
FRONT BUMPER (LIGHTNING SERIES)
HBC8008 2
REAR WHEEL HUB , L,R (LIGHTNING SERIES)
HBC8009-1 1
DIFFERENTIAL CASE (LIGHTNING SERIES)
HBC8019 1
DIFFERENTIAL HOUSING (LIGHTNING SERIES)
HBC8020-1 4
RUBBER SEALED BEARING 8X16MM
HBC8021 3
DIFFERENTIAL PADS (LIGHTNING SERIES)
HBC8022 2
DIFFERENTIAL SHAFT (LIGHTNING SERIES)
HBC8023 6
O-RING 6MM (LIGHTNING SERIES)
HBC8029 1
13T CLUTCH BELL (LIGHTNING SERIES)
HBC8043 3
3PCS RACING CLUTCH SHOE (LIGHTNING SERIES)
HBC8045 3
CLUTCH SPRINGS FOR C8043, C8043-1 (LIGHTNING SERIES)
HBC8048 4
DISK BRAKE PLATE (LIGHTNING SERIES)
HBC8050 4
3X14MM SCREWS (4PCS/LIGHTNING SERIES)
HBC8058-1 1
SW. DUST-PROOF COVER BLACK (LIGHTNING SERIES)
HBC8059 1
CENTER GEAR HOUSING (LIGHTNING SERIES)
HBC8064 2
FRONT & REAR DIFF AXLE SHAFT (LIGHTNING SERIES)
HBC8071 2
CENTER DIFF AXLE SHAFT (LIGHTNING SERIES)
HBC8086 1
ANTENNA (LIGHTNING SERIES)
HBC8088 4
6X10MM SEALED BEARING (LIGHTNING SERIES)
HBC8089 4
BALL FOR STEERING PUSH ROD (LIGHTNING SERIES)
HBC8096 4
3X17MM SHAFT (LIGHTNING SERIES)
HBC8098 4
FIXING BALL FOR UPPER SUSPENSION
HBC8099 4
FIXING BALL FOR REAR SUSPENSION
HBC8100 4
6.8MM BALL END (L/LIGHTNING SERIES)
HBC8101-1 1
HARD STEEL DIFFERENTIAL GEAR SET
HBC8108 1
FRONT STABILIZER SET (LIGHTNING SERIES)
HBC8165 2
TURN BUCKLE 5X85MM
HBC8182 1
50T CENTER GEAR
HBC9010 1
43T SPIRAL BEVEL GEAR (LIGHTNING STADIUM)
Z083
10 FLAT HEAD SCREW M3X10MM (HEX SOCKET)
Z084
10 FLAT HEAD SCREW M3X12MM (HEX SOCKET)
Z086
10 FLAT HEAD SCREW M3X18MM (HEX SOCKET)
Z087
10 FLAT HEAD SCREW M3X20MM (HEX SOCKET)
Z216
4
BUTTON HEAD SCREW M3X15MM (HEX SOCKET)
Z224
10 WASHER M3X8MM
Z242
20 E CLIP E2MM
Z307
4
FLAT HEAD SCREW M4X10MM
Z351
10 BUTTON HEAD HEX SOCKET SCREW M3X6MM
Z352
10 BUTTON HEAD SCREW M3X8MM (HEX SOCKET)
Z353
10 BUTTON HEAD SCREW M3X10MM (HEX SOCKET)
Z354
10 BUTTON HEAD SCREW M3X12MM (HEX SOCKET)
Z357
10 BUTTON HEAD SCREW M3X20MM (HEX SOCKET)
Z492
8
TP. BINDER HEAD SCREW M2.2X4.8MM
Z542
12 CAP HEAD SCREW M3X8MM
Z544
6
CAP HEAD SCREW M3X12MM
Z547
6
CAP HEAD SCREW M3X20MM
Z548
12 CAP HEAD SCREW M3X22MM
Z653
6
NUT M3
Z663
6
LOCK NUT M3
Z664
4
LOCK NUT M4
Z700
6
SET SCREW M3X3MM
Z702
10 SET SCREW M3X5MM
Z704
10 SET SCREW M3X8MM
Z721
4
SET SCREW M4X4MM
Z725
6
SET SCREW M4X10MM
Z740
6
SET SCREW M5X4MM BLACK
Z800
20 SPRING WASHER 3X6MM
Parts # Qty Description
66887
1
HB FACTORY PHILLIPS SCREWDRIVER (6.0X100MM)
66888
1
HB FACTORY PHILLIPS SCREWDRIVER (4.0X100MM)
66889
1
HB FACTORY SLOTTED SCREWDRIVER (4.0X130MM)
66890
1
HB FACTORY SOCKET DRIVER (7.0X80MM)
66891
1
HB FACTORY SOCKET DRIVER (5.5X80MM)
66892
1
HB FACTORY BALL ALLEN WRENCH (2.5X100MM)
66893
1
HB FACTORY BALL ALLEN WRENCH (2.0X100MM)
66894
1
HB FACTORY ALLEN WRENCH (3.0X100MM)
66895
1
HB FACTORY ALLEN WRENCH (2.5X100MM)
66896
1
HB FACTORY ALLEN WRENCH (2.0X100MM)
66897
1
HB FACTORY ALLEN WRENCH (1.5X100MM)
66898
1
HB FACTORY TURNBUCKLE WRENCH (3.7X80MM)
66899
1
HB FACTORY DROOP GAGE
66900
2
HB FACTORY DROOP GAGE BLOCK (20X115MM)
67191
1
LIGHT WEIGHT 43T SPIRAL BEVEL GEAR
67195
2
LIGHT WEIGHT STEERING POST
67196
2
LIGHT WEIGHT WHEEL HEX HUB
67197
2
LIGHT WEIGHT OUT DRIVES
67198
2
LIGHT WEIGHT BRAKE CAM
67200
2
LIGHT WEIGHT DIFFERENTIAL SHAFT
67202
2
LIGHT WEIGHT SHOCK STAND OFF
67203
2
LIGHT WEIGHT STEERING BUSHING
67211
2
LIGHT WEIGHT DIFF. AXLE SHAFT
67434
2
BIG BORE SHOCK SPRING ADJUST NUT
67437
2
BIG BORE SHOCK BOTTOM CAP (PURPLE)
67448
2
BIG BORE SHOCK SPRING (BLUE/60MM/89GF)
67449
2
BIG BORE SHOCK SPRING (ORANGE/60MM/98GF)
67450
2
BIG BORE SHOCK SPRING (GREEN/68MM/59GF)
67451
2
BIG BORE SHOCK SPRING (YELLOW/68MM/68GF)
67452
2
BIG BORE SHOCK SPRING (RED/68MM/81GF)
67453
2
BIG BORE SHOCK SPRING (GRAY/76MM/52GF)
67454
2
BIG BORE SHOCK SPRING (WHITE/76MM/59GF)
67455
2
BIG BORE SHOCK SPRING (BLUE/76MM/63GF)
67456
2
BIG BORE SHOCK SPRING (ORANGE/76MM/74GF)
HBC8051 1
1/8 DECK WING (LIGHTNING SERIES)
HBC8051-1 1
1/8 DECK WING BLACK (LIGHTNING SERIES)
HBC8122-1 1
SHOCK OIL #250
HBC8122-10 1
SHOCK OIL #550
HBC8122-11 1
SHOCK OIL #600
HBC8122-12 1
SHOCK OIL #1000
HBC8122-13 1
SHOCK OIL #5000
HBC8122-14 1
SHOCK OIL #10000
HBC8122-15 1
SHOCK OIL #650
HBC8122-16 1
SHOCK OIL #700
HBC8122-17 1
SHOCK OIL #2000
HBC8122-2 1
SHOCK OIL #350
HBC8122-3 1
SHOCK OIL #450
HBC8122-4 1
SHOCK OIL #3000
HBC8122-5 1
SHOCK OIL #4000
HBC8122-6 1
SHOCK OIL #7000
HBC8122-7 1
SHOCK OIL #300
HBC8122-8 1
SHOCK OIL #400
HBC8122-9 1
SHOCK OIL #500
Parts # Qty Description
Parts # Qty Description
En
Option Parts List
