Benutzerhandbuch K&F SEQUENZA 10 N/W/B & Flugrahmen
KLING & FREITAG GMBH © 2014 Version Version 6.1 Seite 47 von 73
17.2 Anschluss der SEQUENZA 10 N/W
MAIN OUT
6 x SEQUENZA 10 N/W
LF: CH 1: 1+ / 1-
LF / HF: CH 2: 2+ / 2-
1+
CH 1
Introduction -
2+
CH 2
not_found -
3+
CH 3
not_found -
4+
CH 4
Symbols in User's Manual -
LF: CH 3: 1+ / 1-
LF / HF: CH 4: 2+ / 2-
TO NEXT
SYSTEM RACK
Caption:
SEQUENZA 10 - Speaker - Patch - Cable
with NLT4FX cable connectors
SEQUENZA 10 - Speaker Cable Splice
1x NL8MPR Chassis connector to
2x NLT4FX cable connector
SEQUENZA 10 - Prof. Speaker Cable
with NLT8FX - BAG Cable Connectors
K&F SystemRack
K&F CD 44:
Loaded LS Blocks
InfoWindow 2
1:SEQ10LF FR
2:SEQ10LF/HF FR
3:SEQ10LF FR
4:SEQ10LF/HF FR
