Introduction
3 · Audio-Transceiver-Fiber
Introduction
By using two signal extenders of the Audio-Transceiver-Fiber series, you can transmit
audio signals between a computer and a remote console via fiber optic connection.
Audio signals are transmitted in both directions between the connected extenders.
A rotary switch lets you amplify the analogue audio signal coming in at the interface
Line In/Micro In (see page 6).
Package contents
 1 × Signal extender Audio-Transceiver-Fiber
 1 × Portable power pack
 1 × Power cable
 2 × Audio cable (Audio-M/M-2-ferrite)
 1 × Service cable (USB-Service-2)
 1 × Manual
NOTE: Signal extenders of the Audio-Transceiver-Fiber series are provided in
two variants:

Audio-Transceiver-Fiber(S) transmits signals via single-mode optical fibers
over distances up to 10 kilometers.
 Audio-Transceiver-Fiber(M) transmits signals via multi-mode optical fibers
over distances up to 550 meters.
IMPORTANT: Transmitting audio signals requires two signal extenders. The package
contents given below refer to one device.
NOTE: The following SPDIF cables are available as optional accessories:
 A6300119: Audio-SPDIF-COAX-M/M-2 (2 meters)
 A6300120: Audio-SPDIF-COAX-M/M-3 (3 meters)
 A6300121: Audio-SPDIF-COAX-M/M-5 (5 meters)
