Technical data
15 · Audio-Transceiver-Fiber
Features of transmissions modules
MULTIMODE TRANSMISSION MODULE
Data transmission
Type:
Optical fibers (2 optical fibers)
Type of interface:
LC duplex
Cable length (max.)
Multimode 50/125 μm, class OM2:
550 meters
Multimode 62,5/125 μm, class OM1:
250 meters
Performance data
Wavelength (
λ
):
850 nm (770 nm to 860 nm)
Optical output power (P
AVG
)
in 50 or 62,5
μ
m MMF:
-9.0 dBm to-2.5 dBm
Receiving sensitivity (P
MIN
):
-18 dBm
Sensitivity – Stressed (P
S
):
-13.5 dBm (50
μ
m MMF)
SINGLEMODE TRANSMISSION MODULE
Data transmission
Type:
Optical fibers (2 optical fibers)
Type of interface:
LC duplex
Cable length (max.)
Singlemode 9/125μm, Class OS1:
10 kilometers
Wavelength (
λ
):
1310 nm (1270 nm to 1360 nm)
Performance data
Optical output power (P
AVG
)
in 9 μm SMF:
-9.5 dBm to-3 dBm
Receiving sensitivity (P
MIN
):
-19 dBm
Sensitivity – Stressed (P
S
):
-14.5 dBm
